Crawler crane Liebherr LR 1800-1.0

Main Data:

Model / Type of crane LR 1800-1.0 / CC

Max. capacity (75%) / max. loadmoment (tm) 800 t at 9 m / 11200 tm

Year / First taken into operation 2020 / 01.04.2020

Working hours chasis (h) / date - h / 19.03.2023

Working hours superstructure (h) / date 2725 h / 19.03.2023

Mileage (km) / date - km / 19.03.2023

Data Chassis:

Crawler chassis 11,00 m

Support plates 2,00 m

no. of driving gears 4

central counterweight 70 t

Mechanical outriggers existing / available

Hydraulic assembly jacks existing / available

Data Superstructure:

Main boom "HS" 96 m

Main boom "HSL2" 174 m

Lattice-type luffing jib "W" 96 m

Derrick boom "D" 39 m

Counterweight frame "B" 20 t / Vario Tray

Suspended ballast V-frame existing / available

Derrick counterweight 380 t

Fixed fly jib "F" 39 m

Whip line / type 25 t

Boom head 450 t / L

Boom head 650 t / S

Variable equipment S 90 m

Variable equipment SL 114 m

Variable equipment HSL3 102 m

Variable equipment SLF 90 m + 39 m

Variable equipment SLAF 102 m + 39 m

Variable equipment HSL3F 90 m + 39 m

Variable equipment HSL3AF 96 m + 39 m

Variable equipment HSL2DBV 174 m

Variable equipment HSL2ADFBV 159 m + 39 m

Variable equipment SW1 48 m + 96 m

Variable equipment HSDWB 96 m + 96 m

Variable equipment HSDB 120 m

Variable equipment HSLDBV 180 m

Variable equipment HSLDFBV 168 m + 39 m

Variable equipment HSL2ZDBV 171 m

Variable equipment HSL2AZDFBV 162 m + 39 m

No. of winches 6

Winch 1 cable pull / cable Ø 200 kN / 30 mm

Winch 2 cable pull / cable Ø 200 kN / 30 mm

Winch 3 cable pull / cable Ø existing / available

Winch 4 cable pull / cable Ø existing / available

Winch 5 cable pull / cable Ø existing / available

Winch 6 cable pull / cable Ø 125 kN / 25 mm

Engine (make/type) / hp / kW Liebherr D 9508 A7-05 / 619 / 455

Engine exhaust-stage V

Superstructure counterweight 210 t

No. of slewing gears 2

Hookblocks / Crane hook (t) 700 - 350 t / 270 - 135 t / 210 t / 20 t

Assembly cylinder for crawler support existing / available

Quick Connection existing / available

Mobile pin pulling device existing / available

Safe load indicator Liebherr LICCON / 75%

UVV-acceptance validity 01.24

Other features:

Diesel-auxiliary power pack for air condition; ZA-frame

Subject to change.

Subject to prior sale.

Complete data sheet on request.
